| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 411566 | SOLENOID – throttle | 1 |
| 1 | 446544 | * SOLENOID (less plunger & eye bolt) | 1 |
| 2 | 448198 | * PLUNGER | 1 |
| 2 | 2040475 | * GREASE – plunger | A/R |
| 3 | 913095 | * BOOT – plunger | 1 |
| 4 | 552762 | * BOLT – eye | 1 |
| 4 | 551533 | * NUT | 1 |
| 4 | 551800TKA | * LOCKWASHER | 1 |
| 5 | 927051 | BRACKET – solenoid | 1 |
| 6 | 555022 | SCREW – bracket | 4 |
| 6 | 550790 | LOCKWASHER | 4 |
| 6 | 554613 | FLATWASHER | 4 |
| 7 | 554118 | NUT – solenoid | 4 |
| 7 | 550411 | FLATWASHER | 4 |
| 8 | 445087 | TERMINAL – solenoid (part of main harness) | 1 |
| 9 | 442756 | DIODE | 1 |
| 9 | 2030436 | SEALER – diode | A/R |
| 9 | 550346 | NUT – harness & diode | 4 |
| 9 | 552996 | LOCKWASHER (internal tooth) | 4 |
| 9 | 550401 | FLATWASHER | 4 |
| 10 | 118014 | JOINT – solenoid to rod (socket & ball) | 1 |
| 11 | 555292 | NUT | 1 |
| 12 | 923865 | ROD – speed control | 1 |
| 13 | 552752 | NUT | 2 |
| 14 | 130383 | JOINT – rod to lever (socket only) | 1 |
| 15 | 130836 | LEVER – injection control | 1 |
| 16 | 930709 | BRACKET – speed control (interim tier 4 engine) | 1 |
| 17 | 132615 | JOINT – ball | 1 |
| 18 | 511206 | NUT – ball joint | 1 |
208C9
112D9
931160
204F5
