OIL SUMP GROUP (TK486 series)

$8,061.95

Description :

A-0183

ref

part-no

Clear

A-0183

REF	PART NO.	DESCRIPTION	QTY
1	120868	SUMP – oil (upper)	1
2	120869	SUMP – oil (lower)	1
3	558437	* PLUG – drain	2
4	2030348	GASKET – adhesive (RTV silicone)	A/R
5	556246	SCREW – oil base (25 mm)	15
6	555809	SCREW – oil base (45 mm)	19
7	556237	SCREW – oil base (85 mm)	12
8	511150TKA	SCREW – oil base (120 mm)	1
9	118667	DIPSTICK	1
10	334090	O-RING – dipstick	1
11	118923	CAP (units w/o oil level switch, push-in type)	1
12	559167	ELBOW – hose (90 degree)	1
13	118984	HOSE – oil drain (10 in long)	1
13	115911	HOSE – oil drain (17 in long)	1
14	555081	CAP – hose	1
15	914823	CLIP – hose	1
15	551587	SCREW – clip	1
15	552086	FLATWASHER	1
15	554953	NUT	1
16	917191	BRACKET – clip	1
17	414470	SWITCH – oil level (threaded type)	1
17	334160	* O-RING – switch	1
18	119338	VALVE – oil drain	1
19	119448	FITTING – oil drain (ESOC)	1
20	553744	ELBOW – hose (45 degree)	1
21	131063	FITTING – oil drain w/cap	1
