| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 130357 | PIPE – oil | 1 |
| 2 | 554644 | BOLT – eye | 1 |
| 3 | 333833TKA | SEAL – washer (10) | 2 |
| 4 | 555792 | NUT | 1 |
| 5 | 511158 | BOLT – eye | 1 |
| 6 | 554622TKA | WASHER – sealing (8) | 2 |
| 7 | 1010362 | PUMP – fuel injection (2200 rpm, see 204G1) | 1 |
| 7 | 1010354 | PUMP – fuel injection (2600 rpm) | 1 |
| 8 | 511159 | PLUG | 1 |
| 9 | 334089TKA | O-RING – pipe | 1 |
| 10 | 130356 | PIPE – oil pickup | 1 |
| 11 | 558441 | SCREW – pipe (16 mm) | 2 |
| 12 | 130323 | COVER – oil pump (w/ check valve) | 1 |
| 13 | 511147 | * PLUG | 1 |
| 14 | 130325 | * SPRING | 1 |
| 15 | 130324 | * VALVE – check | 1 |
| 16 | 130326 | * COVER – oil pump | 1 |
| 17 | 130328 | ROTOR – outer | 1 |
| 18 | 130327 | ROTOR – inner | 1 |
| 19 | 510592 | SCREW – oil pump | 7 |
| 20 | 332931 | GASKET – oil filter bracket | 1 |
| 21 | 119354 | BRACKET – filter (incl 22 – 30) | 1 |
| 22 | 118964 | * ORIFICE | 1 |
| 23 | 510593 | * PLUG (3/8) | 1 |
| 24 | 555763 | * PLUG (1/8) | 2 |
| 25 | 118995 | * VALVE – check | 1 |
| 26 | 511157 | ** WASHER – sealing (14) | 1 |
| 27 | 118965 | ** SPRING | 1 |
| 28 | 558868 | * BALL | 1 |
| 29 | 511156TKA | * PLUG | 1 |
| 30 | 511157 | * WASHER – sealing (14) | 1 |
| 31 | 556188TKA | SCREW – bracket (20 mm) | 1 |
| 32 | 555809 | SCREW – bracket (45 mm) | 1 |
| 33 | 558869 | SCREW – bracket (75 mm) | 1 |
| 34 | 119182 | FILTER – oil (EMI 3000) | 1 |
| 35 | 119447 | FITTING – oil inlet (ESOC) | 1 |
