| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 300352 | KIT – gasket set | 1 |
| 1 | 335056 | * GASKET – cylinder head (all 2200 rpm engine & 2600 rpm engines built before 3/08) | 1 |
| 2 | 333098 | * GASKET | 1 |
| 3 | 331953 | * O-RING – fuel injection pump | 1 |
| 4 | 118935 | * SEAL – valve stem (exhaust) | 4 |
| 4 | 118934 | * SEAL – valve stem (intake) | 4 |
| 5 | 130341TKA | * PROTECTOR – nozzle | 4 |
| 6 | 116707 | * GASKET – copper (nozzle seat) | 4 |
| 7 | 130340 | * GASKET – valve cover | 1 |
| 8 | 332764 | * GASKET | 1 |
| 9 | 332936 | * GASKET – intake manifold | 1 |
| 10 | 332937 | * GASKET – exhaust manifold | 1 |
| 11 | 332931 | * GASKET | 1 |
| 12 | 333096 | * GASKET – water pump | 1 |
| 13 | 331745 | * WASHER – sealing (16) | 1 |
| 13 | 333833TKA | * WASHER – sealing (10) | 2 |
| 13 | 554622TKA | * WASHER – sealing (8) | 12 |
| 14 | 332767 | * GASKET | 1 |
| 15 | 332768 | * GASKET | 1 |
| 16 | 332765 | * GASKET – air heater | 1 |
| 17 | 332934TKA | * GASKET – flange | 1 |
| 18 | 332969 | * GASKET – oil seal case | 1 |
| 19 | 333097 | * GASKET – thermostat case | 1 |
| 20 | 333512 | * O-RING (12.0) | 3 |
| 20 | 333821TKA | * O-RING (16.0) | 2 |
| 20 | 334089TKA | * O-RING (20) | 1 |
| 20 | 334090 | * O-RING (31.5) | 1 |
| 20 | 331954 | * O-RING (32.0) | 3 |
| 20 | 332762TKA | * O-RING (50.0) | 1 |
| 21 | 2030348 | * GASKET – adhesive (RTV silicone) | A/R |
| 22 | 334517 | GASKET – cylinder head (2600 rpm engines built after 3/08) | 1 |
