FUEL PUMP ASSEMBLY (TK486 series)

$3,271.35

Description :

A-0150

ref

part-no

Clear

A-0150

REF	PART NO.	DESCRIPTION	QTY
1	117433	PUMP – fuel, complete	1
1	NSS	HOUSING – pump	1
2	118970	PISTON	1
3	118971	SPRING – piston	1
4	558871	RETAINER	1
5	332940	GASKET	1
6	118998	TAPPET	1
7	115890	GUIDE	2
8	115889	PIN	1
9	112770TKA	ROLLER	1
10	118974TKA	RETAINER – valve	1
11	332941	O-RING	1
12	118680	PUMP	1
13	118975	JOINT – banjo	1
14	332771	O-RING	1
15	118976	BOLT – eye	1
16	118977	GASKET	2
17	117499	JOINT – banjo (elbow, before engine S/N L68462)	1
17	130128	JOINT – banjo (elbow, engine S/N L68462 & after)	1
18	118681	BOLT – eye (with screen)	1
18	112854	SCREEN (brass, #30)	1
19	552208	GASKET – ring	4
20	130127	JOINT – banjo (straight, engine S/N L68462 & after)	1
20	117707	JOINT – banjo (straight, before engine S/N L68462)	1
21	118682	BOLT – eye	1
22	558872	PIN – snap	1
23	118972TKA	VALVE	2
24	118973	SPRING	2
25	332942	O-RING	1
26	554750	NUT	3
27	556367	STUD – fuel pump	3
