| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 1010362 | PUMP – fuel injection (2200 rpm, see 204G2) | 1 |
| 1 | 1010354 | PUMP – fuel injection (2600 rpm, see 205C5) | 1 |
| 2 | 130365 | BRACKET – pump | 1 |
| 3 | 556188TKA | SCREW – support | 2 |
| 4 | 130371TKA | PIPE – fuel injection | 1 |
| 5 | 130391TKA | PIPE – fuel injection | 1 |
| 6 | 130392TKA | PIPE – fuel injection | 1 |
| 7 | 130393 | PIPE – fuel injection | 1 |
| 8 | 130368 | RETAINER – tube (4 tubes) | 1 |
| 9 | 558626 | SCREW – retainer | 1 |
| 10 | 116109 | RETAINER – tube (3 tubes) | 1 |
| 11 | 558626 | SCREW – retainer | 1 |
| 12 | 130388 | NOZZLE – injection (2200 rpm engine) | 4 |
| 12 | 130389 | NOZZLE – injection (2600 rpm engine) | 4 |
| 13 | 334174TKA | * GASKET – nozzle | 1 |
| 14 | 130341TKA | PROTECTOR – nozzle | 1 |
| 15 | 116707 | GASKET – copper (nozzle seat) | 1 |
| 16 | 100373 | KIT – fuel return | 1 |
| 17 | 130310 | HOSE & CLAMPS (nozzle to nozzle) | 3 |
| 18 | 130451TKA | HOSE & CLAMPS (nozzle to pump) | 1 |
| 19 | 2041848 | ADAPTER – compression tester | 1 |
| 19 | 119446 | * VALVE (Schrader) | 1 |
| 19 | 551819 | * SEAL – copper | 1 |
| 19 | 554607 | * FLATWASHER | 2 |
| 19 | 2040542 | TESTER – compression | 1 |
208C9
226E2
209C4
8101394
