ENGINE MOUNTING

$1,269.92

Description :

A-0162

ref

part-no

Clear

A-0162

REF	PART NO.	DESCRIPTION	QTY
1	920226TKA	BRACKET – generator (rear)	1
1	925252	BRACKET – generator (rear, Maersk blue)	1
1	552963	SCREW – bracket	4
1	552958	FLATWASHER	4
1	552959	LOCKWASHER	4
2	552557	SCREW – frame	2
3	552038	FLATWASHER	2
4	553595	WASHER – special	4
5	554952	NUT	2
6	993649	MOUNT – vibration	2
7	985826	BRACKET – generator (bottom)	1
7	557412	SCREW – generator bracket	4
7	558337	LOCKWASHER	4
7	556999	FLATWASHER	4
8	556814	STUD – power pack	6
9	553512	WASHER – special	12
10	991433	MOUNT – vibration	6
11	991916	MOUNT – vibration	6
12	991642	SPACER	6
13	555205	NUT	6
14	920225TKA	BRACKET – engine	1
14	925253	BRACKET – engine (Maersk blue)	1
15	915700TKA	BRACKET – engine (rear)	1
15	925249	BRACKET – engine (rear, Maersk blue)	1
16	915699TKA	BRACKET – engine (front)	1
16	925250	BRACKET – engine (front, Maersk blue)	1
16	557730	SCREW – engine bracket	8
16	557123	WASHER – belleville (3/8, ss)	8
