| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 130344 | PIPE – breather | 1 |
| 2 | 558442 | * CLAMP – hose (24) | 2 |
| 3 | 913542 | TUBE – sponge (insulation, cut to 11.0 in lg) | 1 |
| 4 | 130337 | COVER – valve | 1 |
| 5 | 130340 | * GASKET – valve cover | 1 |
| 6 | 115103 | * KNOB – valve cover | 3 |
| 7 | 333512 | * O-RING – cover | 3 |
| 8 | 118671 | * BAFFLE – breather | 1 |
| 9 | 130338 | * PLATE – baffle | 1 |
| 10 | 332762TKA | * O-RING | 1 |
| 11 | 130339 | * COVER – breather | 1 |
| 12 | 510598TKA | * SCREW – cover | 8 |
| 13 | 130332TKA | SHAFT – rocker arm | 1 |
| 13 | 130335 | * SHAFT – rocker arm | 1 |
| 14 | 130333 | * SUPPORT – rocker arm | 2 |
| 15 | 130334 | * SUPPORT – rocker arm | 3 |
| 16 | 556245 | * STUD – valve cover | 3 |
| 17 | 116704 | * SPRING | 4 |
| 18 | 130336 | * ARM – rocker | 8 |
| 19 | 558859 | ** SCREW – valve adjust | 8 |
| 20 | 558860 | ** NUT | 8 |
| 21 | 556193 | SCREW – support (50 mm) | 7 |
| 22 | 556246 | SCREW – support (25 mm) | 3 |
| 23 | 121092 | HEAD – cylinder | 1 |
| 24 | 116567 | * PLUG – frost (40 mm) | 1 |
| 25 | 555803 | * PIN – spring | 2 |
| 26 | 130932 | * VALVE – intake | 4 |
| 27 | 118928 | * GUIDE – valve (intake) | 4 |
| 28 | 118935 | * SEAL – valve stem (intake) | 4 |
| 28 | 130659 | * VALVE – exhaust | 4 |
| 30 | 118929 | * GUIDE – valve (exhaust) | 4 |
| 31 | 118934 | * SEAL – valve stem (exhaust, marked w/ yellow stripe) | 4 |
| 32 | 118932 | * SPRING – valve | 8 |
| 33 | 118933 | * RETAINER – spring | 8 |
| 34 | 558858 | * KEEPER – valve | 8 |
| 35 | 118936 | * CAP – valve | 8 |
| 36 | 130342TKA | RETAINER – nozzle | 4 |
| 37 | 130341TKA | PROTECTOR – nozzle | 4 |
| 38 | 116707 | GASKET – copper (nozzle seat) | 4 |
| 39 | 556191 | SCREW – nozzle retainer | 4 |
| 40 | 511151 | WASHER | 4 |
| 41 | 558853 | SCREW – cylinder head | 18 |
| 42 | 335056 | GASKET – cylinder head, rev. 3 (see Service Bulletin TT537) | 1 |
| 42 | 335504 | GASKET – cylinder head, rev. 5 (see Service Bulletin TT537) | 1 |
| 43 | 130126 | LIFTER – engine | 2 |
| 44 | 555801 | SCREW – lifter | 4 |
| 45 | 118942 | FLANGE | 1 |
| 46 | 555763 | * PLUG | 1 |
| 47 | 332934TKA | GASKET – flange | 1 |
| 48 | 558441 | SCREW – flange | 4 |
| 48 | 2030348 | GASKET – liquid | A/R |
| 50 | 130648 | SEAT – valve (intake) | 4 |
| 51 | 118927 | SEAT – valve (exhaust) | 4 |
