| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 131064 | PISTON (std, incl 2-4) | 4 |
| 1 | 131065 | PISTON (w/ ring, 0.25 mm os) | 4 |
| 1 | 131066 | PISTON (w/ ring, 0.50 mm os) | 4 |
| 2 | 130355 | * RING SET (std) | 2 |
| 2 | 130461TKA | * RING SET (0.25 mm os) | 4 |
| 2 | 130455 | * RING SET (0.50 mm os) | 4 |
| 3 | 118950 | * PIN – piston | 4 |
| 4 | 118951 | * CIRCLIP | 8 |
| 5 | 118952 | ROD – connecting | 4 |
| 6 | 118953 | * BUSHING – piston pin | 4 |
| 7 | 130924 | * BEARING – connecting rod (std) | 4 |
| 7 | 130925 | * BEARING – connecting rod (0.25 mm os) | 4 |
| 8 | 558865TKA | * BOLT – connecting rod | 8 |
| 9 | 120750 | FLYWHEEL | 1 |
| 10 | 118947 | * GEAR – ring (before 11/08) | 1 |
| 10 | 131138 | * GEAR – ring (11/08 & after) | 1 |
| 11 | 558864 | BOLT – flywheel | 6 |
| 12 | 555816 | PIN – dowel | 1 |
| 13 | 130351TKA | CRANKSHAFT | 1 |
| 14 | 116719 | * KEY – gear | 1 |
| 15 | 130352TKA | GEAR – crankshaft | 1 |
| 16 | 554668 | PIN – spring | 1 |
| 17 | 130353 | PULLEY – crankshaft | 1 |
| 18 | 556249 | WASHER | 1 |
| 19 | 556250 | BOLT – v-pulley | 1 |
| 20 | 119592 | SPEEDI SLEEVE – front seal | 1 |
