CONTROL BOX DOOR (mP-4000)

$13,973.83

Description :

A-0049

ref

part-no

Clear

A-0049

REF	PART NO.	DESCRIPTION	QTY
1	418723	DOOR – front (mP-4000, includes keypad & VGA display)	1
1	934514	NAMEPLATE – mP-4000	1
1	2043125	TOOL – tester (mP-4000)	1
2	334502	GASKET – door	1
3	511844	HINGE – top	2
3	511874TKA	SCREW	6
4	927636	BRACKET – connector	1
5	927637	BRACKET – washer	1
5	511875	RIVET (3 X 10 mm)	4
5	511876	RIVET (3 X 8 mm)	1
6	927638	BRACKET – cable	1
7	927559	BRACKET – lock reinforcement	1
8	511843	PIN – hinge	2
9	452295	CONTROLLER (MP-4000)	1
10	418718	MODULE – blanking	2
11	418717	MODULE – battery	1
12	418724	CABLE – retriever	1
13	412406	CAP – dust	1
14	928690TKA	STRAP – cap	1
15	418716	CABLE – serial (CM-4000 to PM-4000)	1
15	421636	* CONNECTOR – 10-pin (J2 & J17)	2
16	418715	CABLE – serial (cargo)	1
16	419977	* CONNECTOR – 6-pin (J9)	1
17	419974	CONNECTOR – 8-pin (J4)	1
17	419975	CONNECTOR – 9-pin (J1)	1
17	419976	CONNECTOR – 4-pin (J12)	1
17	419978	CONNECTOR – 17-pin (J3)	1
17	421609	CONNECTOR – 8-pin (J28)	1
17	421636	CONNECTOR – 10-pin (J2 & J17)	1
17	422580	CONNECTOR – 6-pin (J34)	1
18	401298	MODULE – 4 pole monitoring	1
18	452338	* MODULE – expansion	1
19	419237	* HARNESS – expansion module	1
20	420353	MODULE – AFAM+	1
20	401161	KIT – RMM+ module (optional)	1
20	452565	* MODULE – RMM+ (only)	1
20	420880	* ANTENNA	1
21	421635	CONNECTOR – 8-pin (digital humidity sensor, com 2, J28)	1
