| REF | PART NO. | DESCRIPTION | QTY |
| 1 | 919048 | BRACKET – air vent handle | 1 |
| 2 | 559442 | SCREW – handle | 1 |
| 2 | 559541 | WASHER – insulation | 4 |
| 2 | 511427 | NUT | 1 |
| 3 | 918100 | SPRING | 1 |
| 4 | 415666 | DEVICE – door position sensor | 1 |
| 5 | 918102 | HANDLE – air vent | 1 |
| 6 | 511458 | SCREW – disk [Ask for Quote] | 1 |
| 7 | 918104 | BRACKET – handle | 1 |
| 8 | 511211TKA | NUT | 2 |
| 8 | 511429 | LOCKWASHER | 1 |
| 8 | 511430 | FLATWASHER | 1 |
| 8 | 559541 | WASHER – insulating | 3 |
| 9 | 511431TKA | NUT – wing | 1 |
| 10 | 918103 | DISK – air vent | 1 |
| 11 | 334255 | GASKET – air vent | 1 |
| 12 | 5090753 | PLATE – air vent | 1 |
| 12 | 557172 | SCREW – plate | 4 |
| 12 | 557075 | FLATWASHER | 4 |
| 12 | 558877 | WASHER (nylon) | 4 |
| 13 | 332944 | GASKET – air vent | 1 |
| 14 | 918663TKA | PROTECTOR – edge | 1 |
| 15 | 929524 | PIN – hinge | 1 |
| 16 | 920440 | NAMEPLATE – Do Not Open Below 0 C | 1 |
| 17 | 559168 | ADAPTER – hose | 1 |
| 18 | 920411 | HINGE – air vent [Ask for Quote] | 1 |
| 18 | 556994 | SCREW – vent hinge | 8 |
| 18 | 557075 | FLATWASHER | 4 |
| 18 | 559541 | WASHER – insulator (8.4 id) | 6 |
| 18 | 557339 | NUT | 6 |
180D9
180D0
158A5
189D7
